These buttons are for jogging the machine. X1, X10, and X100 are incremental jogs and will move the incremental distances configured in Config -> Control 8. Jog SelectionĬONT will put all jogging into continues mode and will continue to jog as long as you hold the jog button. These 8 buttons can be set up for user selected features. These are equivalent to calling M7, M8, and M9 6. You can set a default spindle speed value that will be set any time the system is initialized (reset pressed) by adding S# (where # is the desired speed) in the Initialization Codes sections of the default control configuration.Ĭoolant buttons allow you to toggle the mist and flood outputs. These are equivalent to calling M3, M4, and M5. Spindle control buttons let you directly set the spindle forward, backwards, and stop. You can access this from the Service section, then Maintenance tab, then Interface Config button: The percentages for each can be changed in the X15- Operator Panel settings. The 4 Rapid Override buttons will set the Rapid Override percent and will affect any G00 rapid rate moves. If you are expecting motion and nothing is going, verify your feedrate is not set to 0%.
The feedrate percentage value is shown on the screen. The Feedrate Override knob will modify Feedrate Override percent and will affect any G01 feed rate moves. If the control is off, pressing Reset will power it on.
#Cnc usb controller cv mode full
Reset also does a full cycle stop and rewinds the GCode file. These defaults can be changed in the Initialization Codes sections of the default control configuration. Reset is used to clear alarms and set the machine back to default modals. Check in with MachMotion for more information!Ĭycle stop does a full cancel of the file, turns off the spindle and coolant, and puts the machine in idle. Retract is an optional feature, currently in development and not operational. Cycle start will resume motion and continue file execution. Cycle ControlĬycle Start can be used to start a G-Code file and is also used to start other commands such as MDI and GoTo Commands.įeed Hold is used to pause motion during file run and will leave the spindle on. Emergency Stop will not lose position of machine or require rehoming. Membrane button panel with Jog, Spindle, Coolant, Feed selections, Emergency Stop, Cycle Start, Feed Hold, and Reset ButtonsĮmergency Stop should be used in the event of an emergency and as a safety precaution any time the machine isn't running. Wireless - Optical mouse with scroll wheelġ8 Gauge Steel, Powder Coated Skin.
#Cnc usb controller cv mode software
MachMotion control software installed, powered by Mach4 software coreġ (Machine Network for Ethernet Devices, TCP Modbus, etc.) One External port underneath the keyboard tray for wireless keyboard and mouse. * Additional Estop buttons must be wired in series with this one.Įxternal USB on the face of the control for loading files with a Flash Drive or temporary use with any other auxiliary USB device.
These are the only required connections to make to the control before you turn it on.Ĭonnection to EtherCAT Network (If using EtherCAT Servo Drives)Ĭonnection to Ethernet IP Network (VFD, PLC, Motion Control) The 2000 series control is an iIndustrial PC control with an integrated 21.5" touch screen and membrane operator panel.
#Cnc usb controller cv mode manual
This manual provides an overview the features of the 2050 control.
